Product Description
General Information
Attribute |
Details |
---|---|
Manufacturer |
Bently Nevada |
Series |
3300 |
Model/Part Number |
330400-00-00 |
Model Type |
Accelerometer (Acceleration Transducer) |
Description
The 330400 Accelerometer from Bently Nevada is designed to measure acceleration in industrial applications. It features high sensitivity, wide frequency response, and rugged construction with a hermetically sealed stainless steel case. The sensor provides reliable performance in harsh environments and offers multiple mounting and cable options for versatile applications.
Specifications
Electrical Specifications
Parameter |
Details |
---|---|
Sensitivity |
10.2 mV/m/s² (100 mV/g) ±5% |
Acceleration Range |
490 m/s² (50 g) peak within 10 Hz to 15 kHz |
Amplitude Linearity |
±1% to 490 m/s² (50 g) peak |
Broadband Noise Floor |
0.039 m/s² (0.004 g) rms (10 Hz to 15 kHz) |
Environmental Limits
Parameter |
Details |
---|---|
Operating & Storage Temperature |
-55°C to +121°C (-67°F to +250°F) |
Shock Survivability |
49,050 m/s² (5000 g) peak |
Relative Humidity |
100% condensing, non-submerged (hermetically sealed case) |
Magnetic Field Susceptibility |
<2.21 mm/s²/gauss (225 mg/gauss) [50 gauss, 50-60Hz] |
IP Rating |
Equivalent to IP68 (dust-tight and watertight, sensor only) |
Physical Specifications
Parameter |
Details |
---|---|
Weight (no cable) |
99 g (3.5 oz), typical |
Diameter |
23 mm (0.93 in) |
Height |
59 mm (2.3 in), including mounting stud |
Connector |
3-pin MIL-C-5015 Receptacle |
Case Material |
316L stainless steel |
Mounting Surface |
32 minch rms |
Mounting Torque |
4.1 N·m (3.0 ft·lb) |
Mounting Angle |
Any orientation |
Ordering Information
Accelerometers
Part Number |
Description |
---|---|
330400-AA-BB |
Standard Accelerometer |
330425-AA-BB |
Alternative Accelerometer Model |
Options Available
• A: Mounting Thread Option
• 01 – ¼-28 UNF integral stud
• 02 – M8 X 1 integral stud
• B: Agency Approval Option
• 00 – None
• 05 – Multiple approvals (CSA, ATEX, IECEx)
Interconnect Cables
Part Number-AA |
Cable Length (Feet) |
Cable Length (Meters Approx.) |
---|---|---|
06 |
6 ft |
1.8 m |
08 |
8 ft |
2.4 m |
10 |
10 ft |
3.0 m |
12 |
12 ft |
3.6 m |
15 |
15 ft |
4.5 m |
17 |
17 ft |
5.0 m |
20 |
20 ft |
6.0 m |
25 |
25 ft |
7.6 m |
50 |
50 ft |
15.2 m |
99 |
99 ft |
30.0 m |
