Bently Nevada 330130-080-00-CN Standard Extension Cable

Bently Nevada 330130-080-00-CN Standard Extension Cable

  • Manufacturer: Bently Nevada

  • Product No.: 330130-080-00-CN

  • Condition:1000 in stock

  • Product Type: Standard Extension Cable

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 700g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

General Information

Attribute

Details

Manufacturer

Bently Nevada

Series

3300

Model/Part Number

330130-080-00-CN

Model Type

3300 XL Standard Extension Cable

Extension Cable Material

Cable Type

Material

Standard Cable

75Ω triaxial, fluoroethylene propylene (FEP) insulated

Extended Temperature Range Cable

75Ω triaxial, perfluoroalkoxy (PFA) insulated

Mechanical Specifications

Specification

Details

Minimum Cable Bend Radius

25.4 mm (1.0 in)

Length and Weight

Specification

Details

System Length Options

5 or 9 meters (including extension cable) or 1 meter (probe only)

Total System Weight

0.7 kg (1.5 lb m)

Probe Weight

323 g/m (11.4 oz)

Extension Cable Weight

34 g/m (0.4 oz/ft)

Armored Extension Cable Weight

103 g/m (1.5 oz/ft)

Extension Cable Temperature Range

Cable Type

Operating & Storage Temperature

Standard Cable

-52°C to +177°C (-62°F to +350°F)

Extended Temperature Range Cable

-52°C to +260°C (-62°F to +500°F)

Ordering Information for 3300 XL Standard Extension Cable

Part Number

Description

330130-AAA-BB-CC

Standard 3300 XL Extension Cable Configuration

Configuration Options

Option

Description

A: Cable Length Option

030: 3.0 meters (9.8 feet)  035: 3.5 meters (13.1 feet)  040: 4.0 meters (11.5 feet)  045: 4.5 meters (14.8 feet)  060: 6.0 meters (19.7 feet)  070: 7.0 meters (22.9 feet)  075: 7.5 meters (24.6 feet)  080: 8.0 meters (26.2 feet)  085: 8.5 meters (27.9 feet)

B: Connector Protector and Cable Option

00: Standard cable  01: Armored cable  02: Standard cable with connector protector  03: Armored cable with connector protector  10: FluidLoc cable  11: Armored FluidLoc cable  12: FluidLoc cable with connector protector  13: Armored FluidLoc cable with connector protector

C: Agency Approval Option

00: Not required  05: CSA, ATEX, IECEx Approvals



View full details

Product Description

General Information

Attribute

Details

Manufacturer

Bently Nevada

Series

3300

Model/Part Number

330130-080-00-CN

Model Type

3300 XL Standard Extension Cable

Extension Cable Material

Cable Type

Material

Standard Cable

75Ω triaxial, fluoroethylene propylene (FEP) insulated

Extended Temperature Range Cable

75Ω triaxial, perfluoroalkoxy (PFA) insulated

Mechanical Specifications

Specification

Details

Minimum Cable Bend Radius

25.4 mm (1.0 in)

Length and Weight

Specification

Details

System Length Options

5 or 9 meters (including extension cable) or 1 meter (probe only)

Total System Weight

0.7 kg (1.5 lb m)

Probe Weight

323 g/m (11.4 oz)

Extension Cable Weight

34 g/m (0.4 oz/ft)

Armored Extension Cable Weight

103 g/m (1.5 oz/ft)

Extension Cable Temperature Range

Cable Type

Operating & Storage Temperature

Standard Cable

-52°C to +177°C (-62°F to +350°F)

Extended Temperature Range Cable

-52°C to +260°C (-62°F to +500°F)

Ordering Information for 3300 XL Standard Extension Cable

Part Number

Description

330130-AAA-BB-CC

Standard 3300 XL Extension Cable Configuration

Configuration Options

Option

Description

A: Cable Length Option

030: 3.0 meters (9.8 feet)  035: 3.5 meters (13.1 feet)  040: 4.0 meters (11.5 feet)  045: 4.5 meters (14.8 feet)  060: 6.0 meters (19.7 feet)  070: 7.0 meters (22.9 feet)  075: 7.5 meters (24.6 feet)  080: 8.0 meters (26.2 feet)  085: 8.5 meters (27.9 feet)

B: Connector Protector and Cable Option

00: Standard cable  01: Armored cable  02: Standard cable with connector protector  03: Armored cable with connector protector  10: FluidLoc cable  11: Armored FluidLoc cable  12: FluidLoc cable with connector protector  13: Armored FluidLoc cable with connector protector

C: Agency Approval Option

00: Not required  05: CSA, ATEX, IECEx Approvals



Download PDF file here:

Click to Download PDF
