Bently Nevada 3300/05-22-00-00 rack

Product Overview

• The Bently Nevada 3300/05-22-00-00 is a rack from the 3300/05 series, designed as a durable, accessible, and expandable mounting solution for the 3300 Monitoring System.
• It accommodates a Power Supply, System Monitor, and various types of 3300 Monitors.
• Each monitor position includes a Signal Input/Relay Module position at the rear of the rack.
• The rack mainframe is constructed from injection-molded plastic sections, featuring a conductive anti-static material to dissipate electrostatic discharge.

Technical Information

• Manufacturer: Bently Nevada
• Series: 3300/05
• Model/Part Number: 3300/05-22-00-00
• Model Type: Rack

Ordering Information

• Model: 3300/05 Rack
• Ordering Format: 3300/05-AXX-BXX-CXX
• Option Descriptions:
  • A: Rack Size Option (SDI/DDI Compatible)
    • 21: 4-position
    • 22: 6-position
    • 23: 8-position
    • 24: 10-position
    • 25: 12-position
    • 26: 14-position
    • 27: 8-position 19-inch EIA mounting
    • 31: 4-position with internal barrier bar
    • 32: 6-position with internal barrier bar
    • 33: 8-position with internal barrier bar
    • 34: 10-position with internal barrier bar
    • 35: 12-position with internal barrier bar
    • 36: 14-position with internal barrier bar
    • 37: 8-position 19-inch EIA mounting with internal barrier bar
  • B: Agency Approval Option
    • 00: Not Required
    • 01: CSA/NRTL/C
    • 02: ATEX self-certification (Note: ATEX approval requires the monitor rack to be installed in a weatherproof housing)
  • C: Mounting Option
    • 00: Standard
    • 01: Used in weatherproof housing or for 19-inch EIA rack mounting

Specific Configuration

• Model/Part Number: 3300/05-22-00-00
• Configuration Details:
  • A: 22 - 6-position rack
  • B: 00 - No agency approval required
  • C: 00 - Standard mounting
