Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
1900/65A |
|
Model/Part Number |
1900/65A-01-01-02-00-01 |
|
Model Type |
General Purpose Equipment Monitor |
Power Requirements
|
Attribute |
Details |
|---|---|
|
Input Voltage Range |
18 to 36 Vdc |
|
Operating Current |
0.35 A typical, 1.0 A maximum |
|
Operating Power |
8.5 W typical, 14 W maximum |
Physical Specifications
Monitor Module
• Dimensions (L x W x H): 196.9 mm x 149.4 mm x 74.4 mm (7.75 in x 5.88 in x 2.93 in)
• Weight: 0.77 kg (1.70 lb)
Display Module
• Dimensions (L x W x H): 196.9 mm x 149.4 mm x 32.8 mm (7.75 in x 5.88 in x 1.29 in)
• Weight: 0.40 kg (0.89 lb)
Environmental Specifications
|
Condition |
Temperature Range |
|---|---|
|
Operating |
-20 to +70 ºC (-4 to +158 ºF) |
|
Storage |
-30 to +90 ºC (-22 to +194 ºF) |
Ordering Information
The 1900/65A General Purpose Equipment Monitor includes Configuration Software and is available in multiple configurations:
1900/65A-AA-BB-CC-DD-EE
A: Power Option
|
Option |
Description |
|---|---|
|
00 |
18 to 36 Vdc |
|
01 |
110 to 220 Vac @ 50 to 60 Hz (external supply) |
B: Display Option
|
Option |
Description |
|---|---|
|
00 |
No display |
|
01 |
Attached display (no cable) |
|
02 |
Display with 10’ PVC cable |
|
03 |
Display with 10’ unassembled PVC cable |
|
04 |
Display with 10’ TEF cable |
|
05 |
Display with 10’ unassembled TEF cable |
C: Mounting Option
|
Option |
Description |
|---|---|
|
00 |
None |
|
01 |
DIN rail mount |
|
02 |
Bulkhead Mount |
|
03 |
Fiberglass NEMA 4X/IP66 WP housing with window in door |
|
04 |
1900/55 replacement kit (requires power option A01: 110/220 Vac to 24 Vdc external power supply) |
|
07 |
ProTIM Housing, Wiring, and Mounting Hardware |
D: Approvals Options
|
Option |
Description |
|---|---|
|
00 |
None |
|
01 |
Multiple approvals |
E: Communications Option
|
Option |
Description |
|---|---|
|
00 |
None |
|
01 |
Modbus communications |
