Product Description
🔹 General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Series |
3500/45 |
|
Model/Part Number |
176449-04 + 139554-01 |
|
Description |
3500/45 Position Monitor |
🔹 Description
The 3500/45 Position Monitor is a 4-channel monitoring module used to measure and monitor various types of displacement and position data. It supports a wide range of input signal types including:
-
Proximity Transducers
-
Rotary Position Transducers (RPTs)
-
DC and AC LVDTs (Linear Variable Differential Transformers)
-
Rotary Potentiometers
The module processes and conditions these input signals and compares them against user-programmable alarm thresholds for machinery protection and diagnostics.
🔹 Environmental Limits
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-30°C to +65°C (-22°F to +150°F) (with I/O) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Humidity |
Up to 95% non-condensing |
🔹 Physical Characteristics
▪️ Monitor Module (Main Board)
|
Parameter |
Specification |
|---|---|
|
Dimensions |
241.3 mm x 24.4 mm x 241.8 mm(9.50 in x 0.96 in x 9.52 in) |
|
Weight |
0.91 kg (2.0 lb) |
▪️ I/O Module (139554-01)
|
Parameter |
Specification |
|---|---|
|
Dimensions |
241.3 mm x 24.4 mm x 99.1 mm(9.50 in x 0.96 in x 3.90 in) |
|
Weight |
0.20 kg (0.44 lb) |
🔹 Spares and Configuration
|
Part Number |
Description |
|---|---|
|
176449-04 |
3500/45 Position Monitor Module (Main board only) |
|
139554-01 |
AC LVDT Position I/O Module with Internal Terminations (for use with AC LVDTs) |
