Product Description
Product Overview
The Bently Nevada 1701/10-01 is a FieldMonitor Terminal Base designed for use within the Bently Nevada 1701 FieldMonitor Series, a distributed control system (DCS) solution for machinery protection and monitoring. Manufactured by Bently Nevada, a Baker Hughes company renowned for condition monitoring since 1961, this terminal base serves as a foundational component for mounting and powering FieldMonitor I/O modules, such as proximity, seismic, or temperature monitors. It is tailored for industrial applications like power generation, oil and gas, and machinery packaging, where distributed architecture reduces installation costs and enhances integration with control systems (Web ID 0). Based on Allen-Bradley’s Flex I/O platform, the 1701/10-01 supports a modular, field-mounted design, providing flexibility and reliability for monitoring rotating equipment like turbines and compressors.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 1701 FieldMonitor Series |
| Model/Part Number | 1701/10-01 |
| Description | FieldMonitor Terminal Base |
| Function | Base for mounting and powering FieldMonitor I/O modules |
| Power Supply | 24 VDC |
| Module Capacity | Up to 8 I/O modules (Flex I/O standard) |
| Operating Temperature | -20 °C to +70 °C (-4 °F to +158 °F) |
| Mounting Type | Field-mounted (DIN rail or panel) |
| Dimensions | Approximately 100 mm H x 200 mm W x 75 mm D (3.94 in x 7.87 in x 2.95 in) |
| Weight | 0.5 kg (1.1 lb) |
