Product Description
Product Overview
The Bently Nevada 135613-02-00 is a Transient Data Interface (TDI) Module designed for use within the Bently Nevada 3500 Series Machinery Monitoring System, a distributed control system (DCS) renowned for condition monitoring and machinery protection. Manufactured by Bently Nevada, a Baker Hughes company, this module serves as the primary interface between the 3500 monitoring system and compatible software, such as System 1, enabling the collection of both steady-state and transient waveform data from rotating machinery. It is widely used in industrial applications like power generation, oil and gas, and petrochemical plants to monitor critical equipment such as turbines and compressors, supporting predictive maintenance and protection compliant with API Standard 670 (Web ID 3). The 135613-02-00 integrates advanced communication capabilities, enhancing system connectivity and data management.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 3500 Series |
| Model/Part Number | 135613-02-00 |
| Description | Transient Data Interface (TDI) Module |
| Power Requirements | 24 VDC, 5 A |
| Communication | Ethernet TCP/IP, RS232/RS422/RS485 |
| Protocols Supported | Bently Nevada proprietary, Modbus, Modbus/TCP |
| Operating Temperature | -30 °C to +65 °C (-22 °F to +150 °F) |
| Mounting Type | Rack-mounted (3500 rack, typically Slot 1) |
| Dimensions | 241 mm H x 24.4 mm W x 256 mm D (9.50 in x 0.96 in x 10.10 in) |
| Weight | 0.82 kg (1.81 lb) |
