| Product Series |
CompactLogix (Bulletin 1768 / 1769) |
| Component Type |
PLC & I/O Controller |
| Controller Memory |
3 MB |
| Safety Memory |
1.5 MB |
| Integrated Motion Control |
Yes |
| Max Number of Motion Control Axes (CIP) |
16 |
| Memory Card Option |
SD Card |
| Communications Protocols |
EtherNet/IP, EtherNet/OCPP, DeviceNet, Open Socket |
| Onboard Communication Ports |
Dual Copper Ethernet, USB (programming only) |
| Max Local Expansion Modules |
30 |
| Max Number of EtherNet/IP Nodes |
48 |
| Operating Temperature Range |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range |
-40°C to 85°C (-40°F to 185°F) |
| Max Relative Humidity |
95% RH (non-condensing) |
| Approximate Weight |
0.54 kg (1.18 lb) |
| Module Width |
89.00 mm (3.50 in.) |
