Product Description
The PM865K01 is a high-integrity, SIL3-certified processor unit designed for safety-critical applications in ABB’s AC 800M system. This unit is intended for use in environments requiring stringent safety measures and robust performance.
General Information
| Attribute | Details |
|---|---|
| Product ID | 3BSE031151R1 |
| ABB Type Designation | PM865K01 |
| Catalog Description | PM865K01 Processor Unit HI |
| Medium Description | High integrity, SIL3-certified processor requiring safety manual configuration. |
| RoHS Compliance | Not compliant with RoHS 2 2011/65/EU. Spare part for systems pre-dating July 22, 2017. |
| System Compatibility | AC 800M hardware and 800xA system software versions 4.0 to 6.0. |
Key Features and Benefits
-
SIL3 Certification:
- Ideal for high-integrity safety applications.
- Configuration must adhere to the Safety Manual.
-
High-Performance Processor:
- 96 MHz processor with 32 MB of memory.
-
Comprehensive Package:
Includes essential components:- PM865 Safety CPU.
- TP830 Baseplate.
- TB850, TB807, and TB852 terminators.
- Battery for memory backup (4943013-6).
-
Safety Note:
- No license included in the package.
- For new installations, use the updated PM867K01.
Technical Specifications
Dimensions and Weight
| Parameter | Details |
|---|---|
| Length | 135 mm |
| Height | 186 mm |
| Width | 119 mm |
| Weight | 1.2 kg |
Battery Details
| Attribute | Details |
|---|---|
| Type | Lithium |
| Weight | 9 g |
| Number of Batteries | 1 |
Environmental Compliance
| Parameter | Details |
|---|---|
| RoHS Status | Not compliant (applicable to spare parts for older systems). |
| WEEE Category | Category 5 (small equipment). |
| UN Dangerous Goods Class | Class 9: Miscellaneous hazardous substances and articles. |
| UN Number | UN3091-PI970 |
Applications and Use Cases
The PM865K01 processor unit is a critical component in the following:
- High-integrity safety systems compliant with SIL3 requirements.
- ABB’s AC 800M hardware and 800xA system platforms (versions 4.0–6.0).
- Maintenance, upgrades, and functionality extensions for existing safety installations.
Ordering and Compatibility
| Attribute | Details |
|---|---|
| HS Code | 853710 – Control boards for voltage ≤1,000 V. |
| Customs Tariff Number | 85371091 |
| Recommended Replacement | For new installations, order PM867K01 to meet compliance. |
Certifications and Standards
| Standard | Details |
|---|---|
| System Certification | SIL3 Certified for high-integrity safety applications. |
| Battery Safety | Conforms to portable lithium battery regulations. |
Important Notes
- This unit is intended for use in legacy systems requiring maintenance or upgrades.
- Ensure compliance with local safety qualifications before installation.
- Refer to the Safety Manual for detailed configuration and safety requirements.
