Product Description
Product Overview
ABB's IGCT (Integrated Gate-Commutated Thyristor) Modules, including the 3BHE019719R0101 Gate Unit 91mm and 3BHB026114R0001 (IGCT 5SHY5055L0002; 5.5KV 91MM ASYMMETRIC), are high-power semiconductor devices designed for industrial applications requiring robust voltage and current handling. Manufactured by ABB, these modules support critical tasks such as high-voltage direct current (HVDC) transmission, powerful motor control, reactive power compensation via static VAR compensators (SVCs), industrial power supplies, and renewable energy systems. The 3BHE019719R0101 serves as a gate unit, while the 3BHB026114R0001 is a specific IGCT optimized for high-voltage asymmetric applications, notably used in ACS 5000 water-cooled systems.
Technical Information - 3BHE019719R0101 (Gate Unit 91mm)
| Item |
Specifications |
| Manufacturer |
ABB |
| Product ID |
3BHE019719R0101 |
| ABB Type Designation |
GV C736 BE101 |
| Catalog Description |
Gate Unit 91mm |
| Long Description |
GV C736 BE101 |
| Country of Origin |
China (CN) |
| Customs Tariff Number |
85049099 |
| Product Net Weight |
1.36 kg |
| Gross Weight |
1.36 kg |
| Made to Order |
No |
| Minimum Order Quantity |
1 piece |
| Order Multiple |
1 piece |
| Part Type |
New |
| Selling Unit of Measure |
piece |
| Stocked At (Warehouses) |
FIPSEEXPU, SGRDC002EXPU, CNIAB001EXPU, SGIND002EXPU, AUABB024EXPU |
Technical Information - 3BHB026114R0001 (IGCT 5SHY5055L0002)
| Item |
Specifications |
| Manufacturer |
ABB |
| Product ID |
3BHB026114R0001 |
| ABB Type Designation |
IGCT 5SHY5055L0002 |
| Catalog Description |
IGCT 5SHY5055L0002; 5.5KV 91MM ASYMMETRIC |
| Long Description |
IGCT 5SHY5055L0002 |
| Country of Origin |
Switzerland (CH) |
| Customs Tariff Number |
85413000 |
| Product Net Weight |
3.3 kg |
| Made to Order |
No |
| Minimum Order Quantity |
1 piece |
| Order Multiple |
1 piece |
| Part Type |
New |
| Selling Unit of Measure |
piece |
| Stocked At (Warehouses) |
FIPSEEXPU, SGRDC002EXPU, CNIAB001EXPU, SGIND002EXPU, AUABB024EXPU |
| Where Used (as a spare part) |
ACS 5000 Water Cooled (Quantity: 1 piece) |
Applications
- High-voltage direct current (HVDC) transmission
- Controlling powerful motors
- Reactive power compensation (Static VAR Compensators - SVCs)
- Industrial power supplies
- Renewable energy systems
Specific Configurations
- 3BHE019719R0101 - Gate Unit 91mm:
- Functions as a gate control unit for IGCT modules, supporting high-power switching.
- Designated as GV C736 BE101, optimized for integration into broader IGCT systems.
- 3BHB026114R0001 - IGCT 5SHY5055L0002:
- 5.5 kV asymmetric IGCT with a 91mm form factor.
- Specifically used as a spare part in ACS 5000 water-cooled medium voltage AC drives.
