Product Description
General Information
- Manufacturer: ABB
- Model: 216EA62
- Ordering Information: 1MRB150083R1/C
- Catalog: Procontrol
- Description: Analog Input Unit A/D Converter
- Origin: United States (US)
- HS Code: 85389091
- Dimensions: 16 cm x 16 cm x 12 cm
- Weight: 0.8 kg
Product Overview
The ABB 216EA62 Analog Input Unit A/D Converter is a high-performance module designed to accurately convert analog signals (e.g., temperature, flow, current, voltage) from industrial environments into digital data. This digital information can then be processed by CPUs, enabling seamless integration with programmable logic controllers (PLCs) for advanced process control and monitoring applications.
Main Features
1. Data Acquisition, Storage, and Processing
- Supports accurate measurement and control of various analog quantities.
- User-selectable resolution and accuracy based on application requirements.
2. Input/Output Interface Conditioning
- Incorporates A/D and D/A conversion functions for effective control of analog quantities.
- Ensures smooth interaction with other modules via I/O interfaces.
3. Temperature Measurement Interface
- Direct connection with resistors or thermocouples.
- Enables real-time monitoring of environmental and process temperatures.
4. Communication Interface
- Supports standard hardware interfaces or proprietary protocols.
- Facilitates seamless program and data exchange with external systems.
5. Distributed Control Network
- Compatible with multiple PLCs, enabling centralized management with decentralized control.
- Enhances scalability and adaptability for complex industrial setups.
Applications
The ABB 216EA62 module is widely used in industrial environments for:
- Process Monitoring: Captures and processes analog data from sensors and actuators.
- Temperature Control: Real-time temperature monitoring and control in industrial processes.
- Industrial Automation: Enhances functionality and efficiency in automated systems.
- Distributed Control Systems: Forms part of a larger network for advanced process control.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Analog Input Unit A/D Converter |
| Ordering Information | 1MRB150083R1/C |
| Catalog | Procontrol |
| Dimension | 16 cm x 16 cm x 12 cm |
| Weight | 0.8 kg |
| Functionality | Analog-to-Digital Conversion |
| Temperature Interface | Resistors/Thermocouples Supported |
| Communication Protocol | Standard/Proprietary Options |
| Distributed Network Capability | Supported |
Benefits
- Enhanced Accuracy: High-precision analog-to-digital conversion for critical industrial processes.
- Real-Time Monitoring: Ensures continuous and reliable monitoring of process variables.
- Flexible Integration: Works seamlessly with a variety of PLCs and industrial systems.
- Scalability: Suitable for expanding industrial networks with centralized management.
- Robust Design: Designed for demanding industrial environments, ensuring long-lasting performance.
Conclusion
The ABB 216EA62 Analog Input Unit A/D Converter is a versatile and powerful module, tailored for demanding industrial applications requiring precise measurement and control. Its compatibility with PLCs and ability to build distributed control networks make it an indispensable component in modern automation systems.
