Product Description
🔹 General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
200150-01 |
|
Description |
General Purpose Accelerometer (Trendmaster Pro compatible) |
🔹 Description
The 200150 Accelerometer is a general-purpose, wide-frequency, case-mounted seismic transducer designed for integration with Trendmaster Pro TIMs and Trendmaster 2000 systems. It offers reliable performance in industrial environments with high sensitivity and robust physical characteristics.
🔹 Specifications
Electrical
|
Attribute |
Value |
|---|---|
|
Sensitivity @ 80 Hz (±12%) |
10.2 mV/(m/s²) (100 mV/g) |
|
Measurement Range |
±245 m/s² (±25 g) |
Environmental Limits
|
Attribute |
Value |
|---|---|
|
Axial Shock Limit |
49,050 m/s² pk (5,000 g pk) |
|
Temperature Range |
-40°C to +105°C (-40°F to +221°F) |
|
Sealing (Hermetic) |
5×10⁻⁸ atm·cc/s (max) |
|
Relative Humidity |
100%, condensing (non-submerged) |
Physical
|
Attribute |
Value |
|---|---|
|
Size (Hex x Height) |
17.5 mm x 45.7 mm (11/16 in x 1.8 in) |
|
Weight |
58 g (2.0 oz), typical |
🔹 Ordering Information
|
Model Number |
Description |
|---|---|
|
200150-AA-BB |
General Purpose Accelerometer (Trendmaster Pro) |
Mounting Stud Options (AA)
|
Code |
Stud Type |
|---|---|
|
00 |
No mounting stud provided |
|
01 |
3/8-24 thread, 2 adhesive mount frames with adhesive |
|
02–23 |
Various threaded stud types and adapter configurations |
|
19 |
Quick-Set XDCR adapter, 1-inch hex stud |
|
20 |
3/8-24 thread, 1 magnetic mount base |
Approval Codes (BB)
|
Code |
Description |
|---|---|
|
05 |
Multiple Approvals (CSA, ATEX, IECEx) |
