Product Description
Honeywell FC-DCOM-232/485 CC V2.1 Communication Interface Module
Product Overview
- The Honeywell FC-DCOM-232/485 CC V2.1 is a Communication Interface Module designed for the Safety Manager system, enabling seamless data exchange between RS-232 and RS-485 devices. This module enhances connectivity in industrial automation and building management systems, supporting integration with Honeywell controllers, sensors, and third-party equipment. It is ideal for applications such as process automation, HVAC control, and energy management in industries like oil and gas, chemical, and manufacturing. The module features a compact design and conformal coating for reliable operation in harsh environments.
Technical Specifications
- The FC-DCOM-232/485 CC V2.1 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | FC-DCOM-232/485 CC V2.1 |
| Manufacturer | Honeywell |
| Description | Communication Interface Module (RS-232/RS-485) |
| Series | Safety Manager |
| Communication Ports | 1 x RS-232 (DB9 connector), 2 x RS-485 (terminal block) |
| Input Voltage | 5 VDC ±5%, supplied by Control Processor(s) |
| Input Current | Max 500 mA |
| Baud Rate | Up to 115.2 kbps (selectable, e.g., 9600, 19200, 57600) |
| Transmission Distance | RS-232: Up to 15 m; RS-485: Up to 1200 m |
| Signal Modes | Full-duplex and half-duplex |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Storage Temperature | -25°C to +70°C (-13°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Ingress Protection | IP20 |
| Dimensions | 110 x 70 x 61 mm (4.33 x 2.76 x 2.40 in) |
| Weight | Approx. 0.14 kg (0.31 lb) |
| Mounting | Universal snap-in for DIN EN rails (TS32/TS35) |
Additional Details
- The FC-DCOM-232/485 CC V2.1 includes the following additional information based on its standard use and documentation:
- Function: Bridges RS-232 and RS-485 protocols for bi-directional communication, supporting data logging, device control, and integration in industrial control systems.
- Mounting: Easily mounts on standard DIN EN rails; connects to Control Processor(s) without separate supply wiring, with earthing via supplied terminal for cable shielding.
- Compatibility: Compatible with Honeywell’s Safety Manager system; supports integration with legacy and modern devices using RS-232 or RS-485/422 protocols.
- Configuration: Conformal coated for environmental protection; supports configurable data formats (e.g., 8 data bits, 1 stop bit, no parity) and selectable baud rates for flexible communication.
- Certifications: Meets CE, UL, and other industrial standards for safety and performance.
